圓錐滾子軸承

KEVFUL BEARING

圓錐滾子軸承

基本尺寸			基本額定載荷		軸承類型	軸承圖片	型號
			dynamic	static	Type	Images	Model
d[mm]	D[mm]	B[mm]	C[kN]	C₀[kN]
1016	1270		2750	7500	圓錐滾子軸承		EE 168400/168500
977.9	1130.3		1450	4400	圓錐滾子軸承		LL 687949/910
900	1180		3960	9150	圓錐滾子軸承		BT1B 328214/HA5
857.25	1092.2		2810	7350	圓錐滾子軸承		EE 157337/157430
838.2	1041.4		1900	4800	圓錐滾子軸承		EE 763330/763410
801.688	914.4		1100	3550	圓錐滾子軸承		LL 584449/410
774.7	965.2		1940	4900	圓錐滾子軸承		EE 752305/752380
762	889		1230	3800	圓錐滾子軸承		LL 483449/418
762	889		1870	5850	圓錐滾子軸承		L 183449/410
760	889		1870	5850	圓錐滾子軸承		L 183448/410
760	889		1230	3800	圓錐滾子軸承		LL 483448/418
749.3	990.6		4570	12000	圓錐滾子軸承		LM 283649/610/HA1
723.9	914.4		2050	4900	圓錐滾子軸承		EE 755285/755360
711.2	939.8		2640	6200	圓錐滾子軸承		BT1B 328068/HA4
710	950		2860	6550	圓錐滾子軸承		BT1B 332890/HA1
710	950		2860	6550	圓錐滾子軸承		BT1B 332890
685.8	876.3		2120	5500	圓錐滾子軸承		EE 655270/655345
682.625	965.2		5120	12500	圓錐滾子軸承		332283
682.625	1080		6710	13200	圓錐滾子軸承		BT1B 332705/HA4
680	1000		5610	12700	圓錐滾子軸承		BT1B 332787/HA4
679.45	901.7		3580	9000	圓錐滾子軸承		LM 281849/810/HA4
660.4	812.8		1940	5600	圓錐滾子軸承		L 281147/110
660.4	1000		4400	9500	圓錐滾子軸承		BT1B 334140/HA4
660.4	939.8		3740	8150	圓錐滾子軸承		332383
635	736.6		858	2650	圓錐滾子軸承		80780/80720
609.6	787.4		2160	5300	圓錐滾子軸承		EE 649240/649310
607.72	787.4		2160	5300	圓錐滾子軸承		EE 649239/649310
560	1080		8970	16000	圓錐滾子軸承		BT1B 334018/HA5
558.8	736.6		2330	5700	圓錐滾子軸承		LM 377449/410
558.8	736.6		1830	4150	圓錐滾子軸承		EE 843220/843290
